ML-100L2-4 (3KW, 4 POLE ALIMULIUM BODY THREE PHASE ELEC MOTOR MOUNT - B3)

Boost your machinery's performance with this robust Industrial Electric Motor. Designed for reliability and powerful output, this motor is ideal for compressors, pumps, conveyors, and other heavy-duty industrial applications. Durable construction ensures long-lasting use. Easy to install and energy-efficient.

A single-phase 2.2kW (3HP) 4-pole B3 electric motor runs at approximately 1500 RPM on a 230V 50Hz supply. It features horizontal foot mounting (B3), a standard 100-frame size, and a 28mm shaft diameter, making it ideal for high-torque industrial and agricultural gear.

A 3kW (4 HP) 4-pole single-phase B3 electric motor runs at roughly 1500 RPM on 220–230V, 50Hz power. The B3 designation means it features a foot-mounted design. Units typically cost between 900 AED and 1,200 AED depending on the brand and housing material.

Key Specifications

• Power Output: 3.0 kW (4 Horsepower)

• Speed: 4 Pole (~1400 to 1500 RPM at 50Hz)

• Voltage: 220V – 230V single phase

• Mounting Type: B3 (Foot mount, no face/flange)

• Frame Size: Usually 100 or 132 frame

• Shaft Diameter: Standard 28 mm

• Starting Design: High starting torque via dual capacitors (start/run configuration
